Adaptall 9605-12-L22-30X1.5
Adaptall 9605-12-L22-30X1.5 Light-Duty Straight Adapter, L22 Male Metric DIN 24 deg Tube x 3/4 in Male JIC, Steel
- Manufacturer: Adaptall Inc.
- Brand: Adaptall
- ARGPN: 9605-12-L22-30X1.5
- MPN: 9605-12-L22-30X1.5
-
Available for delivery:
-
Available for pickup at
Anchorage, AK Branch:
-
Available for Adaptall Inc. factory-direct delivery:
-
Adaptall Light-Duty Straight Adapter, Series: 9605, Fitting Type: Adapter, Connection Size 1: L22, Connection Type 1: Male Metric DIN 24 deg Tube, Connection Size 2: 3/4 in, Connection Type 2: Male JIC, Material Construction: Carbon Steel, M30 x 1.5 x 1-1/16-12 Thread, 38 mm Hex, Dimension Standards: DIN 2353, ISO 8434-1, ISO 8434-2, SAE J514, 52.1 mm L
| Connection Size 1 | : | L22 |
| Connection Size 2 | : | 3/4 in |
| Connection Type | : | Male Metric|Male JIC |
| Connection Type 1 | : | Male Metric DIN 24 deg Tube |
| Connection Type 2 | : | Male JIC |
| Dimension Standards | : | DIN 2353, ISO 8434-1, ISO 8434-2, SAE J514 |
| Dimensions | : | 52.1 mm L |
| Fitting Type | : | Adapter |
| Hex Size | : | 38 mm |
| Material | : | Steel |
| Material Construction | : | Carbon Steel |
| Series | : | 9605 |
| Thread Size | : | M30 x 1.5 x 1-1/16-12 |
