Dixon® PL300 PL300

Dixon® PL300

Dixon® PL300 In-Line Oil Lubricator, 1/2 in FPT Inlet, 1/2 in FPT Outlet, 30 scfm, 1.4 fl-oz Capacity

  • Manufacturer: Dixon Valve & Coupling
  • Brand: Dixon®
  • ARGPN: PL300
  • MPN: PL300
  • ARG Industrial Available for delivery: loading
  • ARG Industrial Available for pickup at Anchorage, AK Branch: loading
  • Available for Dixon Valve & Coupling factory-direct delivery: loading
  • loading
  • Add to cart
Add To Favorites
  1. pin-int

Dixon® In-Line Oil Lubricator, Inlet Size: 1/2 in, Outlet Size: 1/2 in, Inlet Connection Type: FPT, Outlet Connection Type: FPT, 30 scfm, 500 psi, Lubricant Capacity: 1.4 fl-oz, Material Construction: Aluminum, Dimensions: 4-1/2 in L x 2-1/4 in W x 2-1/4 in H

California residents see Prop 65 WARNINGS

Dimensions      :      4-1/2 in L x 2-1/4 in W x 2-1/4 in H
Flow Rate      :      30 scfm
Inlet Connection Type      :      NPT
Inlet Size      :      1/2 in
Lubricant Capacity      :      1.4 fl-oz
Material      :      Aluminum
Material Construction      :      Aluminum
Outlet Connection Type      :      NPT
Outlet Size      :      1/2 in
Pressure Rating      :      500 psi
Product Type      :      Oil Lubricator
  • Designed to protect portable or stationary air tools by efficiently oiling the tool mechanisms
  • Each time an air tool is operated, a fine mist of oil is injected into it along with the air from the compressor
  • Use any petroleum-based, non-detergent lightweight oil (SAE 10/150SSU) which will readily break up into a mist, i.e., Mobil DTE light or comparable oil
  • Transparent sight disc allows visual inspection of oil level
  • Oil flow regulated by screwdriver screw adjustment
  • Minimum flow rate is 30 scfm

Instructions: Installation is recommended within 25 ft of the tool to be lubricated.

  • Refer to the arrow for proper air flow direction.

    Safety Notes: Not recommended for constant flow applications.

  • For reciprocating tools only.
  • Do not use any synthetic oil or oils containing additives or solvents.
    • pdfCatalog https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_PL300_CAT.pdf
    • pdfCut Sheet https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_700013016_SS.pdf
    • pdfTechnical Drawing/Parts Diagram https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_PL300_TD.pdf
