Dixon® R15BS-A R15BS-A

Dixon® R15BS-A

Dixon® Holedall™ 520-H Brass Ferrule, 1-1/2 in, 2-3/64 to 2-6/64 in OD

  • Manufacturer: Dixon Valve & Coupling
  • Brand: Dixon®
  • ARGPN: R15BS-A
  • MPN: R15BS-A
  • ARG Industrial Available for delivery: loading
  • ARG Industrial Available for pickup at Anchorage, AK Branch: loading
  • loading
  • Add to cart
Add To Favorites
  1. pin-int

Dixon® Holedall™ Ferrule, Series: 520-H, Nominal Size: 1-1/2 in, 2-3/64 - 2-6/64 in OD, 1-7/16 in Length, Material Construction: Brass, For Use With: Scovill Style Internally Expanding Permanent Couplings

California residents see Prop 65 WARNINGS

For Use With      :      Scovill Style Internally Expanding Permanent Couplings
Length      :      1-7/16 in
Material      :      Brass
Material Construction      :      Brass
Nominal Size      :      1-1/2 in
Outside Diameter      :      2-3/64 - 2-6/64 in
Series      :      520-H
Shape      :      Ferrule
Sub Brand      :      Holedall™

Applications: For discharge and suction service, transfer of fuel to airplanes, homes, ships and more

Safety Notes:

  • Do not interchange with other manufacturer's fittings.
  • Dixon® Holedall stems and ferrules are specifically designed to be used together as a coupling system.
  • Do not use a wrench or vice on ferrule.
  • Holedall couplings, regardless of coupling style, are never to be used for steam service at any pressure.
  • Holedall fittings are not to be used with cable reinforced high-pressure hose, 4 or 6 braid wire hydraulic hose or any other service not listed in the recommendations.
  • Consult Dixon® for recommendations on usage.
  • Strict adherence to ferrule OD range (internally expanded) for each hose end to be assembled is essential for satisfactory performance.
  • Hose service working pressure (including surges and spikes) is never to exceed the maximum recommended working pressure for the fitting.
  • The assembly's (hose + coupling) maximum working pressure is the lesser of the hose rated working pressure or the coupling rated working pressure.
  • Media being transported through the hose should be compatible with the stem material.
  • Compatibility of ferrule material with the environment in which it will be used is recommended.
  • Consult the Compatibility Chart or the Dixon® factory for material compatibility.
  • pdfCatalog https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_1020304C_CAT.pdf
  • pdfCut Sheet https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_R15AAASA_SS.pdf
  • pdfTechnical Drawing/Parts Diagram https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_R15BS-A_TD.pdf
