Weatherhead® 06906D-406

Weatherhead® 069 D Zinc-Plated Carbon Steel Female SAE 45 deg Swivel 3-Piece Field Attachable Reusable Hose End, 5/16 in

Manufacturer: Danfoss Power Solutions
Brand: Weatherhead®
ARGPN: 06906D-406

MPN: 06906D-406

Available for delivery:
Available for pickup at Anchorage, AK Branch:
Available for Danfoss Power Solutions factory-direct delivery:
Add to cart

Description
Specs
Features
Documents

Weatherhead® 3-Piece Field Attachable Reusable Hose End, Series: 069 D, Connection Type 1: Hose, Connection Size 1: 5/16 in, Hose Dash Size: 05, Connection Type 2: SAE 45 deg Swivel, Gender 2: Female, Connection Size 2: 3/8 in, Nominal Size: 3/8 in, Thread Size 2: 5/8-18, Hex Size: 13/16 x 3/4 in, Cut-Off Factor: 1.19 in, Material Construction: Carbon Steel, Finish: Zinc-Plated, For Use With: H069, H166, H169, H229, and H366 Hoses, Dimensions: 2.05 in L, Dimension Standards: SAE 100R5

Connection Size 1	:	5/16 in
Connection Size 2	:	3/8 in
Connection Type	:	Hose~SAE Female Swivel
Connection Type 1	:	Hose
Connection Type 2	:	SAE 45 deg Swivel
Cut-Off Factor	:	1.19 in
Dimension Standards	:	SAE 100R5
Dimensions	:	2.05 in L
Finish	:	Zinc-Plated
Fitting Type	:	Hose End
For Use With	:	H069, H166, H169, H229, and H366 Hoses
Gender 2	:	Female
Hex Size	:	13/16 x 3/4 in
Hose Dash Size	:	05
Material	:	Steel
Material Construction	:	Carbon Steel
Nominal Size	:	3/8 in
Series	:	069 D
Shape	:	Straight
Thread Size 2	:	5/8-18

Very popular in heavy-duty truck markets
Can be used with a variety of hoses allowing for a diverse number of applications

Applications: Medium pressure and high-temperature hose lines a variety of applications including truck, industrial and small engine where temperature may be a problem
